Muncie CS24 and CS25 Series PTO and Parts.
Service Manual, Parts Manualand Owners Manual.
Sales, Service, Parts and Repairs.
Rebuild Kits, Bearing Kits, Seal Kits, Gasket Kits, Shafts, Gears.
KEY FEATURE, BENEFIT
Four remote mount output shafts in both keyed and flange types.
Versatility for remote pump drives.
S.A.E. "A", "B", "BB", and DIN 5462 direct mount pump options.
Fits most popular pumps.
Rotatable direct mount flanges.
Allows pump to be positioned for maximum clearance.
Compatible with PTO Shaft Extensions for Allison transmissions.
Moves the pump mount to the rear of the transmission for large pump clearance.
Patented Muncie drag brake.
Prevents shaft rotation in "OFF" mode.
Two assembly arrangements.
Allows the PTO to be mounted shaft high or low on either side of the transmission.
Uses Include:
Garbage trucks.
Snow and ice plows.
Tankers trucks.
Pump trucks.
Aerial man-lifts.
Dump trucks.
The Muncie CS24 and CS25 Series PTOs are designed with the same technology as the CS10, though 24% smaller, the CS24 and CS25 is still a heavy duty PTO for applications like snow and ice removal, tandem and triple axle dumps, fuel haulers, aircraft refuelers, rear and side loading trash trucks, digger derricks, and aerial devices.
The CS-24 and CS-25 Series PTO have torque ratings ranging from 240 to 325 lb. ft. and features 7 internal speed ratios.
The highest speed ratio is ideal for utility vehicles to obtain the high flow rates from smaller displacement pumps at lower speeds.
Available in 11 different output shaft types including the standard 1-1/4" round, SAE "B" either 2 bolt only or combination 2 and 4 bolt, SAE "A" 2 bolt, SAE "B-B" 2 and 4 bolt and the non standard 4 bolt "G" option. Other output options include a 1410 type companion flange, the DIN 100 companion flange and the DIN 5462 hydraulic mount. The hydraulic flanges are 360° rotatable with multiple mounting positions.
Two housing are available to provide output either high or low for either side of the transmission. This makes installation easy and better suited for today's confined spaces. The CS25 version has a remotely mounted solenoid valve making it more compact.
Weight: 52 lbs.
Housing Construction: Ductile Iron.
Speed Ratios: 7.
Maximum Torque: 325 lb. ft.
Output Shaft Options: 12.
Rotatable Pump Mount Flange:
Standard Assembly Arrangements: 2
Drag Brake: Standard.
Extended Shaft PTO: Yes.
(855) 844-SALE
(855) 844-7253
Service Manual, Parts Manualand Owners Manual.
Sales, Service, Parts and Repairs.
Rebuild Kits, Bearing Kits, Seal Kits, Gasket Kits, Shafts, Gears.
KEY FEATURE, BENEFIT
Four remote mount output shafts in both keyed and flange types.
Versatility for remote pump drives.
S.A.E. "A", "B", "BB", and DIN 5462 direct mount pump options.
Fits most popular pumps.
Rotatable direct mount flanges.
Allows pump to be positioned for maximum clearance.
Compatible with PTO Shaft Extensions for Allison transmissions.
Moves the pump mount to the rear of the transmission for large pump clearance.
Patented Muncie drag brake.
Prevents shaft rotation in "OFF" mode.
Two assembly arrangements.
Allows the PTO to be mounted shaft high or low on either side of the transmission.
Uses Include:
Garbage trucks.
Snow and ice plows.
Tankers trucks.
Pump trucks.
Aerial man-lifts.
Dump trucks.
The Muncie CS24 and CS25 Series PTOs are designed with the same technology as the CS10, though 24% smaller, the CS24 and CS25 is still a heavy duty PTO for applications like snow and ice removal, tandem and triple axle dumps, fuel haulers, aircraft refuelers, rear and side loading trash trucks, digger derricks, and aerial devices.
The CS-24 and CS-25 Series PTO have torque ratings ranging from 240 to 325 lb. ft. and features 7 internal speed ratios.
The highest speed ratio is ideal for utility vehicles to obtain the high flow rates from smaller displacement pumps at lower speeds.
Available in 11 different output shaft types including the standard 1-1/4" round, SAE "B" either 2 bolt only or combination 2 and 4 bolt, SAE "A" 2 bolt, SAE "B-B" 2 and 4 bolt and the non standard 4 bolt "G" option. Other output options include a 1410 type companion flange, the DIN 100 companion flange and the DIN 5462 hydraulic mount. The hydraulic flanges are 360° rotatable with multiple mounting positions.
Two housing are available to provide output either high or low for either side of the transmission. This makes installation easy and better suited for today's confined spaces. The CS25 version has a remotely mounted solenoid valve making it more compact.
Weight: 52 lbs.
Housing Construction: Ductile Iron.
Speed Ratios: 7.
Maximum Torque: 325 lb. ft.
Output Shaft Options: 12.
Rotatable Pump Mount Flange:
Standard Assembly Arrangements: 2
Drag Brake: Standard.
Extended Shaft PTO: Yes.
(855) 844-SALE
(855) 844-7253
Muncie
CS-24 and CS-25
Series PTO
Manual
Downloads:
Muncie CS24 - CS25 Series PTO Service and Parts Manual.
Muncie CS24 - CS25 Series PTO Owners and Install Manual.
CS-24 and CS-25
Series PTO
Manual
Downloads:
Muncie CS24 - CS25 Series PTO Service and Parts Manual.
Muncie CS24 - CS25 Series PTO Owners and Install Manual.
