Muncie FR66 Series PTO and Parts.
Service Manual, Parts Manual and Owners Manual.
Sales, Service, Parts and Repairs. Rebuild Kits, Bearing Kits, Seal Kits, Gasket Kits, Shafts, Gears.
The Ford Super Duty, equipped with the Automatic Transmission and the Muncie FR-66 PTO can deliver up to 200 lb.ft. of torque at fast idle and can transmit live power to your hydraulic system. The FR 66 provides maximum torque capacity with a surprisingly simple installation.
Today's diesel engines don't make it easy for the installation of clutch pumps and mounting kits.
Muncie's FR66 Series Power Take-Off solves that.
The FR66 can deliver up to 200 lb. ft. of torque for stationary applications and mobile applications are possible with up to 120 lb. of torque. No more issues with, low power ratings, replacement belts, and difficult clutch pump installations.
Muncie's FR-66 Series PTO provides maximum torque capacity with a surprisingly simple installation. If the Torqshift automatic is your choice, only the FR series PTO can provide up to 190 Ft-Lbs of output torque.
One year warranty.
SPECIFICATIONS:
28 lbs.
Construction: Ductile Iron.
Max Torque: 200 lb. ft.
Pump Flow @ 1200 RPM: 2.4 / 13.3 GPM.
Standard Output: 1 1/4" diameter.
PTO Output Shaft, direct mount: 3/4"-11.
spline, rotatable pump mount flange: standard.
Uses:
* Dump trucks
* Wreckers
* Snow plows
* Bucket trucks
* Car carriers
* Lift gate
* Cranes
* Hydraulic tools
• ENGINE DRIVEN PTO.
• CLUTCH SHIFT.
• COMPACT DESIGN.
• DUCTILE IRON HOUSING.
• EASY TO INSTALL.
• 200 FT. LBS. TORQUE CAPACITY.
• DIRECT MOUNT HYDRAULIC PUMPS.
• DRIVESHAFT OPTION.
• QUIET OPERATION.
