Muncie 8405A and 8406A Series PTO.
PTO Parts. Parts Manual Service Manual and Owners Manual. Sales, Service and Repairs.
Rebuild Kits, Bearing Kits, Seal Kits, Gasket Kits, Shafts, Gears.
The 8405A and 8406A PTO incorporates a one piece housing design. An 8-bolt mounting pad, direct mount pump flange, and air shift cylinder into a single casting, providing a rigid structure for high vibration environments.
8405A/8406A SERIES
POWER TAKE-OFF
THE 8405/6A
SERIES PROVIDES:
FOR EATON, MERITOR & MACK
TRANSMISSION 8-BOLT OPENINGS
This robust design provides a rigid structure for
high vibration level environments at an economical price.
• INTEGRAL 8-BOLT MOUNTING PAD
• SAE "B" OR SAE "B-B", 2 OR 4-BOLT
PUMP MOUNTING FLANGE AND SHAFT
OPTIONAL 1-¼" RD. SHAFT
• INTEGRAL AIR-SHIFT
• DRAIN PORT
• INSPECTION PORT FOR BACKLASH
ADJUSTMENT
• 3 POPULAR SPEED RATIOS
EQUIVALENT TO THE TG8S-U6807,
08 & 09 PTOS
• INTERMITTENT TORQUE RATING
225 LB.FT.
COMMON APPLICATIONS ARE:
Dump Trucks
Live Floor Trailers
Dump Trailers
Ejector Trailers
SPECIFICATIONS
Weight: 37 lbs.
Housing Construction: Cast Iron
Speed Ratios: 3
Maximum Torque: 225 lb. ft.
Output Shaft Options: 2
Assembly Arrangements: 2
A one-piece, cast iron housing with
high strength & high rigidity.
Integral 8-bolt mounting pad
for easy installation.
Integral air shift with easy installation.
Three pump mounting flanges: S.A.E. "B" and "BB" that fit the most popular hydraulic pumps.
U68 and M65 gear pitches in three speed ratios that fit popular Eaton, Fuller, Mack, and ZF Meritor transmissions.
(855) 844-SALE
(855) 844-7253
PTO Parts. Parts Manual Service Manual and Owners Manual. Sales, Service and Repairs.
Rebuild Kits, Bearing Kits, Seal Kits, Gasket Kits, Shafts, Gears.
The 8405A and 8406A PTO incorporates a one piece housing design. An 8-bolt mounting pad, direct mount pump flange, and air shift cylinder into a single casting, providing a rigid structure for high vibration environments.
8405A/8406A SERIES
POWER TAKE-OFF
THE 8405/6A
SERIES PROVIDES:
FOR EATON, MERITOR & MACK
TRANSMISSION 8-BOLT OPENINGS
This robust design provides a rigid structure for
high vibration level environments at an economical price.
• INTEGRAL 8-BOLT MOUNTING PAD
• SAE "B" OR SAE "B-B", 2 OR 4-BOLT
PUMP MOUNTING FLANGE AND SHAFT
OPTIONAL 1-¼" RD. SHAFT
• INTEGRAL AIR-SHIFT
• DRAIN PORT
• INSPECTION PORT FOR BACKLASH
ADJUSTMENT
• 3 POPULAR SPEED RATIOS
EQUIVALENT TO THE TG8S-U6807,
08 & 09 PTOS
• INTERMITTENT TORQUE RATING
225 LB.FT.
COMMON APPLICATIONS ARE:
Dump Trucks
Live Floor Trailers
Dump Trailers
Ejector Trailers
SPECIFICATIONS
Weight: 37 lbs.
Housing Construction: Cast Iron
Speed Ratios: 3
Maximum Torque: 225 lb. ft.
Output Shaft Options: 2
Assembly Arrangements: 2
A one-piece, cast iron housing with
high strength & high rigidity.
Integral 8-bolt mounting pad
for easy installation.
Integral air shift with easy installation.
Three pump mounting flanges: S.A.E. "B" and "BB" that fit the most popular hydraulic pumps.
U68 and M65 gear pitches in three speed ratios that fit popular Eaton, Fuller, Mack, and ZF Meritor transmissions.
(855) 844-SALE
(855) 844-7253
Muncie 8405A and 8406A
Series PTO Manual Downloads:
Muncie 8405A, 8406A Series PTO Service and Parts Manual.
Muncie 8405A, 8406A Series PTO Owners Manual and Install.
Muncie 8405A, 8406A Series PTO Spanish Owners Manual and Install.
Series PTO Manual Downloads:
Muncie 8405A, 8406A Series PTO Service and Parts Manual.
Muncie 8405A, 8406A Series PTO Owners Manual and Install.
Muncie 8405A, 8406A Series PTO Spanish Owners Manual and Install.
