SG SERIES (Single Gear) PTO
Muncie's single gear PTO covers a wide variety of light and medium duty applications. Strong enough for tow trucks, fuel trucks, dump trucks, utility trucks and aerial lifts up to 25 HP at 1000 RPM, torque to 130 lb. ft. speeds to 2500 RPM. Improved gear design, quiet operation with no chattering.
A lightweight aluminum housing, reduced size and simplified installation. Stronger roller bearings stand up to greater loads. Cable or lever shift with all mounting parts including an in-dash positive indicator light.
The SG Series, single speed, single gear PTO has the simplest design and fewest component parts. The SG is ideally suited for light to medium duty applications. The output shaft of a single gear PTO is close to the transmission so direct mount pump flanges are not available.
KEY FEATURE BENEFIT
Aluminum housing Light weight, quiet
Compact housing Easy installation
Simple design Inexpensive, easy to service
SPECIFICATIONS.
Weight: 6.5 lbs.
Housing: Aluminum
1 Speed Ratios.
21 Gear Pitches Offered.
Shift Type: Cable.
Maximum Torque 130 lb. ft.
Output Shaft Options: 7/8" Round.
2 Assembly Arrangements.
Uses:
* Dump trucks
* Hoists
* Wreckers
* Tilt-back
(855) 844-SALE
(855) 844-7253
SG Series Parts.
Service Manual, Parts Manual and Owners Manuals. PTO Sales, Service, Repairs.
Rebuild Kits, Bearing Kits, Seal Kits, Gasket Kits, Shafts, Gears.
SG SERIES (Single Gear) PTO
Muncie's single gear PTO covers a wide variety of light and medium duty applications. Strong enough for tow trucks, fuel trucks, dump trucks, utility trucks and aerial lifts up to 25 HP at 1000 RPM, torque to 130 lb. ft. speeds to 2500 RPM. Improved gear design, quiet operation with no chattering.
A lightweight aluminum housing, reduced size and simplified installation. Stronger roller bearings stand up to greater loads. Cable or lever shift with all mounting parts including an in-dash positive indicator light.
The SG Series, single speed, single gear PTO has the simplest design and fewest component parts. The SG is ideally suited for light to medium duty applications. The output shaft of a single gear PTO is close to the transmission so direct mount pump flanges are not available.
KEY FEATURE BENEFIT
Aluminum housing Light weight, quiet
Compact housing Easy installation
Simple design Inexpensive, easy to service
SPECIFICATIONS.
Weight: 6.5 lbs.
Housing: Aluminum
1 Speed Ratios.
21 Gear Pitches Offered.
Shift Type: Cable.
Maximum Torque 130 lb. ft.
Output Shaft Options: 7/8" Round.
2 Assembly Arrangements.
Uses:
* Dump trucks
* Hoists
* Wreckers
* Tilt-back
(855) 844-SALE
(855) 844-7253
Muncie
SG Series PTO
Manual
Downloads:
Muncie SG Series PTO Service and Parts Manual.
Muncie SG Series PTO Owners and Install Manual.
Muncie SG Series PTO Spanish Owners and Install Manual
SG Series PTO
Manual
Downloads:
Muncie SG Series PTO Service and Parts Manual.
Muncie SG Series PTO Owners and Install Manual.
Muncie SG Series PTO Spanish Owners and Install Manual
