Muncie CS10 and CS11 Series PTO.
PTO Parts, Service Manual, Parts Manual and Owners Manuals.
Sales, Service, Parts and Repairs.
Rebuild Kits, Bearing Kits, Seal Kits, Gasket Kits, Shafts, Gears.
Muncie CLUTCH SHIFT SERIES CS10 and CS11 PTO.
We offer a Large Inventory of Muncie Products All CS10 and CS11 Series PTO Models and Replacement Parts.
Weight: 68 lbs.
Housing Construction: Ductile Iron Speed Ratios: 5 Maximum Torque: 500 lb. ft.
Output Shaft Options: 10.
Rotatable Pump Mount Flange: Standard Assembly Arrangements: 2 Drag Brake: Standard Muncie, CS10, CS11, Series, Power, Take-Off, Wet Line Kit.
The CS10 and CS11's are rated to 500 lb.ft. torque and 95 H.P. at 1000 RPM.
A versatile PTO for the Allison 3000 & 4000 and Caterpillar CX transmissions.
The CS10 is the PTO designed to handle a wide range of heavy duty applications including dump bodies, utility, refuse, recovery and fire vehicles.
Large gears and a heavy duty housing, the CS10 is rated from 385 to 500 lb.ft. across the 5 available speed ratios.
The location of the output shaft of the CS10 is designed around popular hydraulic pumps and has the ability to accept these pumps without the need to alter the Allison transmission case.
The CS10 is standard with the 1-1/2" 10 spline, 1410 type flange or is available with 1-1/4" keyed output shaft. Also available are SAE "B" 2 and 4 bolt, SAE "C" 2 and 4 bolt, SAE "C" 2 bolt and thenDIN 5462 hydraulic pump mounting flanges.
All CS10 & CS20 Series PTOs have the patented integrated drag brake which assists in stopping the output shaft when the PTO is disengaged. The CS11 version has a remote mount solenoid activation valve for additional clearance of PTO during installation.
The Muncie CS10 and CS 11 Series Power Take-Off.
Clutch Shift PTO designed specifically for Allison and Caterpillar transmissions.
Engaged by means of a solenoid activated wet clutch pack.
Engagement solenoid built into the PTO and requires of only one hose connection.
A remote mounted solenoid is available for compact installations.
